We offer the most complete product innovation in the PP TQ Film Plant
Jailaxmi is one of the reputed PPTQ Film Plant Manufacturer and Supplier. Jailaxmi provide PP TQ Film Plants with variable screw diameters. Jailaxmi PP TQ Film Plant is known for giving excellent output. Jailaxmi PP TQ Film Plant is available at competitive prices.
Features
- Different application for Packing
- Nitrided Screw and Barrel made out from special nitro alloy steel for long life.
- Helical Gear Box with inbuilt Thrust Bearing.
- Specially designed spiral type die.
- PID Temperature Controller.
- AC Motor Synchronization.
Specifications
| Model | JEC-2650 High Output | JEC-2650 (HOTD) Twin Die | JEC-2765 |
| Screw Diameter | 50 mm | 50 mm | 65 mm |
| Extruder Drive (AC variable) | 11 KW | 11 KW | 11 KW |
| L/D Ratio | 30:1 | 30:1 | 30:1 |
| Max Output(Kg/hr) | 40-45 | 40-45 | 70-80 |
| Lay flat Width | 26" | 15" | 30" |
| Thickness Range (Ga.) | 80-300 | 80-300 | 80-300 |
| Dies (Spiral Type) mm | 100 & 200 | 175 (2 Nos.) | 125, 200, 300 |
| Nip Roll Size | 30" | 18" X 2 | 36" |
| Nip Roll Drive (AC variable) | 0.37 KW | 0.55 KW X 2 | 1.5 KW |
| Winder Width | 26" | 18" X 2 | 36" |
| Connected Load | 26 KW | 38 KW | 40 KW |
| Overall Dimensions(ft.) | 18' L X 8' W X 12' H | 20' L X 8' W X 12' H | 20' L X 8' W X 13' H |
