We offer the most complete product innovation in the LLDPE, HM-HDPE, LDPE Film Plant
Jailaxmi LLDPE Film Plant ends with Jailaxmi Engineering Corporation, Jailaxmi is a name to rely upon. Jailaxmi provide LLDPE Film Plan, which can be used to efficiently manufacture the packing bags for different contents. Jailaxmi LLDPE Film Plant is made from special nitro alloy steel that ensures its long life.
Features
- Different application for Packing
- Nitrided Screw and Barrel made out from special nitro alloy steel for long life.
- Helical Gear Box with inbuilt Thrust Bearing.
- Specially designed spiral type die.
- PID Temperature Controller.
- AC Motor Synchronization.
Specifications
| Model | JEC-1150 Twin Die | JEC-1265 |
| Screw Diameter | 50 mm | 65 mm |
| Extruder Drive (AC variable) | 11 KW | 18.5 KW |
| L/D Ratio | 32 : 1 | 32 : 1 |
| Max Output(Kg/hr) | 45-50 | 70-80 |
| Lay flat Width | 12" | 44" |
| Minimum Gauge | 40 | 40 |
| Dies (Spiral Type) mm | 40 & 100 | 75, 125 & 175 |
| Nip Roll Size | 16" | 48" |
| Winder | Two Station | Four Station |
| Connected Load | 28 KW | 45 KW |
| Overall Dimensions(ft.) | 15' L X 10' W X 12' H | 22' L X 14' W X 17' H |
